Free 2 Bed Bold House Plan – 1,347 Sq Ft

2 bedroom bold house plan exterior - 1,347 sq ft

Materials

Blue

Blue

Cladding

Red Brick

Red Brick

Foundation

Red / Barn Red

Red / Barn Red

Roofing

Black

Black

Windows & Trim

Black

Black

Front Door

About This Design

This bold design spans 1,347 square feet, featuring a single bedroom and two bathrooms. The exterior combines dark blue horizontal siding with a striking red metal hip roof and a contrasting red brick foundation. Inside, the layout includes a spacious 515 sqft living area, a 119 sqft kitchen, and a generous 332 sqft primary bedroom complete with its own closet and bathroom. This compact home measures 30 by 45 feet, offering an efficient and visually distinctive living space.

Features

  • hip
  • none
  • siding
  • brick

Interior Layout

The floor plan below shows the room arrangement, walls, and doorways. Hover over rooms to see their names and dimensions.

2 bedroom bold floor plan showing 2 bathrooms - 1,347 sq ft

Shape & Structure

The footprint shows the outline and proportions of this design.

Footprint

Loading footprint...

3D Preview

Loading 3D preview...

Move forward
with this design

Click above to see preview

Share and print ready PDF

Present and compare designs with clients, builders, and family

Workflow-ready Plan DXF

Layered polylines with block-based doors and windows (download example)

Works with your tools

Import into AutoCAD, Revit, SketchUp, Chief Architect, and more
