About This Design
This 1,078 SF industrial house features 1 bedroom and 1 bathroom, designed efficiently within a 14' x 80' footprint. The exterior showcases sleek corrugated metal siding, complemented by a unique living green roof and a stone foundation. The interior includes a primary bedroom, family room, dining, kitchen, and dedicated laundry, offering a functional and contemporary living space.
Features
- flat
- none
- corrugated metal
- stone
- green roof
Interior Layout
The floor plan below shows the room arrangement, walls, and doorways. Hover over rooms to see their names and dimensions.
Shape & Structure
The footprint shows the outline and proportions of this design.
