Free 5 Bed Dark House Plan – 4,508 Sq Ft

5 bedroom dark house plan exterior - 4,508 sq ft

Materials

Standing Seam Black

Standing Seam Black

Cladding

Cultured Stone

Cultured Stone

Foundation

Onyx Black

Onyx Black

Roofing

Dark Bronze

Dark Bronze

Windows & Trim

Black

Black

Front Door

About This Design

This 4,508 sqft Dark home features 5 bedrooms and 4 bathrooms. The exterior showcases dark vertical wood siding, a stone base, and warm wood-trimmed windows, creating a contemporary facade. Amenities include a spacious living area with a fireplace, a large kitchen, a dedicated office, and a practical mudroom. A 2-car attached garage and a covered front porch are also included.

Features

  • hip
  • 2-car attached
  • wood siding
  • stone
  • covered porch
  • dormers

Interior Layout

The floor plan below shows the room arrangement, walls, and doorways. Hover over rooms to see their names and dimensions.

5 bedroom dark floor plan showing 4 bathrooms - 4,508 sq ft

Shape & Structure

The footprint shows the outline and proportions of this design.

Footprint

Loading footprint...

3D Preview

Loading 3D preview...

Make this plan yours

Remix this house and explore versions made from the same plan.

Move forward
with this design

Click above to see preview

Share and print ready PDF

Present and compare designs with clients, builders, and family

Workflow-ready Plan DXF

Layered polylines with block-based doors and windows (download example)

Works with your tools

Import into AutoCAD, Revit, SketchUp, Chief Architect, and more
