About This Design
This 5,421 sq ft Dark house plan features 5 bedrooms and 7 bathrooms, offering ample space across its 84' x 72' footprint. The exterior showcases robust dark stone cladding and large windows, complemented by a welcoming covered front porch. An attached 2-car garage provides practical convenience, while an expansive outdoor living area extends the functional space.
Features
- hip
- 2-car attached
- stone
- covered porch
- large windows
- outdoor living
Interior Layout
The floor plan below shows the room arrangement, walls, and doorways. Hover over rooms to see their names and dimensions.
Shape & Structure
The footprint shows the outline and proportions of this design.
Footprint
