Free 4 Bed Earthy House Plan – 3,804 Sq Ft

4 bedroom earthy house plan exterior - 3,804 sq ft

Materials

Beige / Sand

Beige / Sand

Cladding

Fieldstone

Fieldstone

Foundation

Onyx Black

Onyx Black

Roofing

Putty / Almond

Putty / Almond

Windows & Trim

Black

Black

Front Door

About This Design

This 3,804 sq ft Earthy house design offers 4 bedrooms and 6 bathrooms. The exterior features warm tan siding paired with a stone base and a dark hip roof. Key amenities include a generous 630 sq ft attached garage, a welcoming front porch, and an expansive 426 sq ft outdoor living area. The interior provides a dedicated office, a primary suite with ample closet and bath, and open-concept living spaces like kitchen, dining, and living rooms.

Features

  • hip
  • 2-car attached
  • siding
  • stone
  • covered porch

Interior Layout

The floor plan below shows the room arrangement, walls, and doorways. Hover over rooms to see their names and dimensions.

4 bedroom earthy floor plan showing 5 bathrooms - 3,804 sq ft

Shape & Structure

The footprint shows the outline and proportions of this design.

Footprint

Loading footprint...

3D Preview

Loading 3D preview...

Move forward
with this design

Click above to see preview

Share and print ready PDF

Present and compare designs with clients, builders, and family

Workflow-ready Plan DXF

Layered polylines with block-based doors and windows (download example)

Works with your tools

Import into AutoCAD, Revit, SketchUp, Chief Architect, and more
